Name

A unique and representative name that identifies the application being registered.

Grant type

Authorization Code

Used to integrate web or mobile applications in which the application receives an authorization code via the redirect URL. Before obtaining the token, the authorization code is sent to the authorization server to reduce the possibility of attackers obtaining the token directly.

Client certificate

Allows authentication using a certificate. When this option is selected, the Allowed Scope is automatically set to ODATA QUERY, which is the only available scope for this grant type. This method enhances security for consuming OData services, as the application sends a signed JWT validated against the certificate uploaded in Bizagi.

Client credentials

Used to obtain an access token in the context of a user (for example, to obtain an access token as an administrator). This option is commonly used when you need to use a Bizagi feature without considering all application users (for example, when using the OData layer as the admon user). With this grant type, there is no need to send an authorization code, as the OAuth keys are validated directly to obtain the access token.

All

Used to obtain a token via an Authorization Code, Client credentials, or a Bearer token.

Bearer token

Used as an HTTP authentication scheme, allowing an external application using the OAuth key pair to obtain an access token directly by sending these keys in the authorization header of the HTTP request (for example, when synchronizing users using SCIM). This grant type is recommended when using an HTTPS secure connection.

Web site

Associated website URL.

Allowed Scope

API

When selected, the token allows full use of the OData services.

LOGIN

When selected, the token allows the Bizagi project to act as an IdP (authenticator) to access other Bizagi projects. This scope is especially recommended when using Authorization Code as the grant type.

USER SYNC

When selected, Bizagi uses the SCIM standard to retrieve user information from an external system. You must select this scope when synchronizing users through SCIM.

ODATA QUERY

When selected, the token grants specific permission to execute Work Portal queries using the Query endpoint of the OData services. This is the only available scope for applications using Client certificate as the grant type.

RPA

When selected, the token grants permission to respond to Automation Anywhere Callbacks.

User Name

Applies when using Client credentials, Client certificate, or All as the grant type.

Specify the name of an existing Bizagi user (make sure to select it from the suggested list of matching users).

Security recommendation: When selecting the user name associated with the OAuth 2.0 application, avoid using the default administrator account. Assign a user with the minimum privileges required to perform the intended integration tasks. Granting elevated roles (such as administrators) increases the risk of data exposure through the OData API if the client credentials (clientID and clientSecret) are compromised.

Bizagi does not enforce default role restrictions, so it is your responsibility to define and assign appropriate roles. We also recommended to rotate the clientSecret periodically to reduce the risk of credential misuse.

User Domain

The domain to which the previously selected user belongs.

Redirect Strategy

Web Application

Redirects the user to a web URI using the code obtained from the authorization server.

Mobile Title Bar Browser

Used when the application redirects the user to a mobile device app. Since mobile devices do not have an endpoint, the request is redirected by sending the authorization code in the HTML title tag, so the mobile device can extract it from there.

Mobile Localhost Port

Bizagi sends a code to https://localhost:port/, where a mobile device can retrieve the one sent by the authorization server.

Redirect URI

Applies when using Authorization Code or All as the grant type.

URL to which the user is redirected in the callback after providing their credentials. The URL should always be defined using HTTPS.

Token lifetime (mins)

The number of minutes a token remains valid and can be reused for another invocation. This limit enhances security while avoiding replay attacks. If no value is specified, Bizagi considers the token to never expire (infinite lifetime).

Life cycle type

Absolute

Token life cycle type in which the authentication session expires once the token lifetime ends, regardless of whether the external system was used or not. When a timeout occurs, a new token must be negotiated.

Sliding

Token life cycle type in which the authentication session expires once the token lifetime ends, but unlike the absolute type, the session time resets each time the external system is used.

Description

A brief description of the registration.

Public key (.cer)

Applies only to the Client Certificate grant type.

Upload the public certificate file provided by your IT team or system administrator.
